Tank Lining Coatings are two component, high build amine adduct cured phenolic epoxy primer systems specifically designed for internal lining of storage tanks. These coatings provide excellent resistance to chemicals, solvents, fuels, water, and aggressive media. Tank lining coatings form a tough, impermeable barrier that protects steel substrates from corrosion and contamination, making them ideal for chemical, petroleum, water, and industrial storage tanks.
| Sr. No | Product | Description | DFT (µm) | Colour | Finish | Mixing Ratio | Drying / Curing | Applications |
|---|---|---|---|---|---|---|---|---|
| 1 | PHENGUARD 930 | Two component high build amine adduct cured phenolic epoxy primer for chemical resistance. | 100 | Off-white | Eggshell | 88 : 12 |
Touch dry: 120 min @20°C Overcoating: 36 hrs @20°C Full cure: 21 days @20°C |
Chemical and petroleum storage tanks |
| 2 | PHENGUARD 935 | Two component high build amine adduct cured phenolic epoxy coating for aggressive chemicals. | 100 | Pink | Eggshell | 88 : 12 |
Touch dry: 120 min @20°C Overcoating: 24 hrs @20°C Full cure: 21 days @20°C |
Chemical storage tanks and process vessels |
| 3 | PHENGUARD 940 | Two component high build amine adduct cured phenolic epoxy finish for tank linings. | 100 | Light Grey | Eggshell | 88 : 12 |
Touch dry: 120 min @20°C Overcoating: 24 hrs @20°C Full cure: 21 days @20°C |
Petroleum and chemical storage tanks |
| 4 | PHENGUARD 965 | Two component high build amine adduct cured phenolic epoxy coating for fast return to service. | 100 | Off-white / Pink / Grey | Eggshell | 87 : 13 |
Touch dry: 120–180 min @20°C Overcoating: 8 hrs @20°C Full cure: 14 days @20°C |
Chemical tanks and storage vessels |
| 5 | SIGMAGUARD CSF 650 | Two component solvent-free amine cured epoxy tank lining coating. | 300–600 | Green / Off-white / Clear | Glossy | 80 : 20 |
Touch dry: 480 min @20°C Overcoating: 24 hrs @20°C Full cure: 20 days @20°C |
Storage tanks for chemicals and fuels |
| 6 | SIGMAGUARD CSF 585 | Two component solvent-free amine cured epoxy coating for immersion service. | 250–400 | Blue / White | Glossy | 77.5 : 22.5 |
Touch dry: 300 min @20°C Overcoating: 24 hrs @20°C Full cure: 20 days @20°C |
Water and chemical storage tanks |
| 7 | SIGMASHIELD 905 | Two component glassflake reinforced solvent-free amine cured epoxy coating. | 400–500 | Green | Glossy | 80 : 20 |
Touch dry: 480 min @20°C Overcoating: 24 hrs @20°C Full cure: 20 days @20°C |
Heavy-duty tank linings and immersion service |
| 8 | NOVAGUARD 840 | Two component solvent-free amine cured novolac phenolic epoxy tank lining. | 300–600 | Cream / Green / Clear | Glossy | 80 : 20 |
Touch dry: 360 min @20°C Overcoating: 24 hrs @20°C Full cure: 2 months @20°C |
Chemical, petroleum and aggressive media tanks |
| 9 | Apoguard SE 156 | Solvent free, high build, heavy duty epoxy coating for tank internal lining (BIS & POTABLE WATER certified). | 400–800 | Grey / Redoxide / White | Glossy | 3 : 1 |
Touch dry: 120 min Overcoating: 8 hrs Full cure: 4 days |
Potable water tanks, chemical storage tanks, heavy duty internal linings |
| 10 | Apodur CF 698 | Self-priming, amine base high build epoxy coating for tank internal lining. | 75–125 | Off-white & Grey | Egg-shell | 4 : 1 |
Touch dry: 120 min Overcoating: 12 hrs Full cure: 5 days |
Chemical tanks, petroleum tanks, internal corrosion protection |
| 11 | Apodur CF 707 | High build epoxy phenolic coating for tank internal service. | 100–150 | Greyish Black | Egg-shell | 5 : 1 |
Touch dry: 6 hrs Overcoating: 16 hrs Full cure: 5 days |
Chemical and petroleum storage tanks, aggressive internal environments |
